Features of cooling fan:

1. Energy saving: the power consumption of energy-saving and environmental protection air conditioner and wet curtain wall cooling system is only one eighth of that of traditional compressed air conditioner.

2. Fresh air and odor removal: the outdoor air is filtered and cooled by the environmental protection air conditioner, sending out fresh, cool and oxygen rich air

3. Less investment in energy-saving and environmental protection air conditioning, low initial installation cost, economy and durability, no need for professional maintenance personnel.

4. Energy saving and environmental protection air conditioning, wet curtain wall cooling system environmental protection does not contain freon, no pollution.

Application scope

  Industry: textile, machinery, injection molding, casting, rubber, toys, printing, socks, electronics, laundry, boiler room, etc

Industrial plant cooling.

  The cooling principle of the air conditioner (evaporative air conditioner) is: when the fan is running, it enters the cavity to generate negative pressure, so that the air outside the fan flows through the porous wet curtain surface, forcing the dry bulb temperature of the air passing through the curtain to close to the wet bulb temperature of the air outside the fan, that is, the dry bulb temperature at the outlet of the air conditioner is 5-12 ℃ lower than that of the outdoor dry bulb temperature (the dry and hot area can reach 15 ℃), and the more dry and hot the air, the greater the temperature difference , the better the cooling effect. Because the air is always introduced into the room from the outside, (this time called positive pressure system), it can keep the indoor air fresh; at the same time, because the machine uses the evaporation cooling principle, it has the dual functions of cooling and humidifying (relative humidity can reach about 75%). When it is used in workshops such as textile and knitting, it can not only improve the cooling and humidifying conditions, but also purify the air and reduce the over spinning of needles The broken rate of the needle in the process can improve the quality of the needle textile products. The air conditioner (evaporative air conditioner) is surrounded by honeycomb wet curtains made of special materials, which have a large surface area. The wet curtains are continuously humidified through the water circulation system. The wet curtain air conditioner is equipped with an efficient, low-noise and energy-saving fan. When the fan is running, the negative pressure of the wet curtain air conditioner is generated, which makes the air outside the machine flow through the porous wet curtain into the machine. Because of the evaporation of water on the wet curtain It absorbs heat and forces the air through the wet curtain to cool down. At the same time, the water on the wet curtain evaporates to the air flowing through the wet curtain, increasing the humidity of the air, so the wet curtain cooling fan has dual functions of cooling and humidifying.

Industrial cooling fan:

  Dry cooling fan is commonly used in industry. It relies on the air through the evaporation exhaust pipe in the cooling fan to cool the forced flow air outside the pipe. It is installed on the floor of the cold storage, which is called floor type cold fan; it is installed on the top of the warehouse, which is called top type cold fan.

Air conditioners (evaporative air conditioners) cover the whole country

  The main production base is in Fujian, and now it has radiated to all regions of Fujian and Sichuan, Guangdong, Zhejiang, Xinjiang, Hunan, Hubei, Guangxi, Henan, Hebei, Shandong, Shanxi, Jiangxi, Jiangsu, Yunnan, Guizhou, Anhui, Ningxia, Qinghai, Gansu, Shaanxi, Hainan, Inner Mongolia, Beijing, Shanghai, Chongqing, Tianjin, Taiwan, Hong Kong, Macao.

Main features of cooling fan

① less investment, high efficiency (only about 1 / 8 of the power consumption of traditional central air conditioning) ② the use of cold fans can not close the doors and windows. ③ it can replace the indoor turbid, sultry and peculiar smell air and discharge it out of the room. ④ the power consumption is small, and the power consumption per hour of each set is 1.1 degrees, without freon. ⑤ air volume of each cooling fan: 6000-80000m3. ⑥ each cold air covers an area of 100-130 square meters. ⑦ cooling main part (wet curtain).

Features of steam type cooling fan:

1. Obvious cooling effect: in the humid area (such as the south area), the obvious cooling effect of about 5-6 ℃ can be achieved generally;

2. Ventilation, air exchange, dust prevention, odor removal and temperature reduction are integrated to increase air oxygen content and work efficiency.

3. It is equipped with the functions of automatic water supply, automatic air swing, automatic cleaning and air supply, which can realize the automatic phase loss protection.

  The structural types of air cooler include floor type (L), floor top side blowing (LS), floor bottom side blowing (LX), floor flat blowing (LP), ceiling type (d), assembly type (PP, PD), etc;

  The traditional high-efficiency cooling fan is the equipment that outputs the cooling capacity in the refrigeration system, which is mainly composed of cooling coil and axial-flow fan. Through the forced action of axial-flow fan, the air in the room to be cooled is forced to convective heat exchange through the cooling exhaust pipe group of the cooling fan, so as to cool the air, so as to achieve the purpose of reducing the room (or warehouse) temperature.
